wilk301
WILK301
- Product Type: Induction lighting voltage tester
- Test Range (DC): About 12-1000V DC, high sensitivity
- Test Range (AC): About 48-1000V AC, non-contact
Fast live/neutral wire identification with sound and light indication for safe electrical work. (Model WILK301)
Key Features
- Shell Material：Imported ABS.PC
- Test probe material is copper Screwdriver material S2
- The inspection is according to GB8218-2003 .
- The sampling standard is according to GB8218-87 S-4
- Voltage
- test range:About 12-1000V/DC (high sensitivity)
- About 48-1000V/AC (low sensitivity)
- Induction frequency:50/60HZ
- Alarm mode:Audible and visual alarm
- Automatic shutdown:Automatic shutdown without operation for one minute
- Low battery prompt:When the battery power is lower than 2.6V, The sound prompt will be
- given, and it will automatically shut down after starting
- ambient temperature:0℃∽70℃(32°F∽158°F)
- ±2℃/±4°F
- NCV sensitivity adjustment:Key switch
- Zero-fire line judgment:According to the weak voltage
- signal, the strong voltage is the live line
- Breakpoint judgment:Single-strand line electrification
- judgment, judge the position according to the alarm signal
- source:lithium cell3.7V(150mah) size 4*20*30mm
- Product standby power consumption:<5uA
- Charging current:<220mA
- Charging interface:Type-C
- Product size:92×52×24mm
- Product weight:Bare computer about 70g
- Safety level:CE CAT III 1000V/CAT IV 600V
Product Information
- Series
- Alte instrumente
- Model
- WILK301
- SKU
- wilk301
- Product Type
- Induction lighting voltage tester
- Test Range (DC)
- About 12-1000V DC, high sensitivity
- Test Range (AC)
- About 48-1000V AC, non-contact
Specifications
| Function | WILK301 |
|---|---|
| Product Type | Induction lighting voltage tester |
| Test Range (DC) | About 12-1000V DC, high sensitivity |
| Test Range (AC) | About 48-1000V AC, non-contact |
| Induction Frequency | 50/60Hz |
| Alarm | Audible and visual alarm |
| Auto Shutdown | After 1 minute without operation |
| Low Battery Warning | Below 2.6V |
| Body | Food-grade silicone strap, ABS and PC |
| Inspection Standard | GB8218-2003 |
| Sampling Standard | GB8218-87 S-4 |
Application
This instrument is designed for electrical testing, installation and diagnostics across residential, commercial and industrial settings. Contact our team to discuss your specific application.
General Information
Packaging
Packing: not provided Packing quantity: not provided Carton size: not provided G.W./N.W.: not provided
Product Details
FAQs
What is the minimum order quantity for wholesale?
We serve both small trial orders and container-scale wholesale. Tell us the models and quantity you need, and our sales team will reply with pricing and lead time within 24 hours.
Do you support OEM/ODM with our own brand?
Yes. As a factory founded in 2008, we offer OEM/ODM services including custom labels, packaging and adjustable measuring ranges. Send us your specifications and we will handle the rest.
What certifications do your instruments have?
Our instruments are CE, RoHS and ISO 9001 compliant, and we can provide the relevant certificates on request.
What is your warranty?
Every instrument ships with a 12-month warranty. If a unit is defective, contact us and we will arrange a replacement or repair.
How do you ship orders, and what is the lead time?
Orders ship from our factory in Wenzhou, and we can arrange FOB Wenzhou or FOB Ningbo, whichever suits your freight forwarder best. For sea freight we pack into cartons and pallets sized for a 20ft or 40ft container, and for small or urgent orders we ship by air or express. In-stock catalog models ship within 3 to 7 days after payment, while OEM orders with custom branding take 15 to 30 days depending on the work.
What are your payment terms?
For bulk orders we work on T/T bank transfer with a 30% deposit to confirm production and the 70% balance before shipment. For larger amounts we also accept L/C at sight. For sample orders we take PayPal or full T/T in advance, so your first test order stays simple.
Can I get samples to evaluate before ordering in bulk?
Yes, we encourage a sample order before you commit to bulk, so you can check build quality and calibration yourself. Samples are sent by express and usually arrive within 3 to 7 working days, and we refund the sample cost from your first bulk order of the same model. Just send us the models you want through the contact form or email, and we will quote the sample and ship on payment.
What export documents do you provide for customs clearance?
We provide a commercial invoice, packing list and certificate of origin with every shipment, plus CE and RoHS certificates and test reports when needed. Our export team prepares the documents to match your country's customs requirements and can amend them if your forwarder requests changes. The documents are sent by email ahead of the goods, so clearance at your port is not delayed.
